Total 1 entry
Total 1 entry matched
00001. (172.168.0.2, 227.0.0.1)
MID: 0, Flags: 0x0:0
Uptime: 00:08:32, Timeout in: 00:03:26
Incoming interface: GigabitEthernet0/1
List of 1 outgoing interfaces:
1: GigabitEthernet0/2
Matched 19648 packets(20512512 bytes), Wrong If 0 packets
Forwarded 19648 packets(20512512 bytes)
Table 91 Output description
Field Descri
p
tion
Multicast Forwarding Table of
VPN-Instance: public net
Multicast forwarding table for the public network
Total 1 entry Total number of (S, G) entries in the multicast forwarding table
Total 1 entry matched
Total number of matched (S, G) entries in the multicast forwarding
table
00001 Sequence number of the (S, G) entry
(172.168.0.2,227.0.0.1) An (S, G) entry of the multicast forwarding table
MID (S, G) entry ID. Each (S, G) entry has a unique MID
Flags
Current state of the (S, G) entry. Different bits are used to indicate
different states of (S, G) entries. Major values of this field are
described in Table 92.
Uptime
Length of time for which the (S, G) entry has been up, in
hours:minutes:seconds
Timeout in
Length of time in which the (S, G) entry will expire, in
hours:minutes:seconds
Incoming interface Incoming interface of the (S, G) entry
List of 1 outgoing interface:
1: GigabitEthernet0/2
Outgoing interface list
Interface number: outgoing interface name and number
Matched 19648 packets (20512512
bytes), Wrong If 0 packets
(S, G)-matched packets (bytes), packets with incoming interface
errors
Forwarded 19648 packets (20512512
bytes)
(S, G)-forwarded packets (bytes)
Table 92 Major values of the flags field
Value Meanin
g
0x00000001 Indicates that a register-stop message must be sent
0x00000002 Indicates whether the multicast source corresponding to the (S, G) is active
0x00000004 Indicates a null forwarding entry
