383
Multicast routing tables are the basis of multicast forwarding. You can view the establishment state of an
(S, G) entry by checking the multicast routing table.
Related commands: display multicast forwarding-table.
Examples
# View the routing information in the multicast routing table of the public instance.
<Sysname> display multicast routing-table
Multicast routing table of VPN-Instance: public net
Total 1 entry
00001. (172.168.0.2, 227.0.0.1)
Uptime: 00:00:28
Upstream Interface: GigabitEthernet0/1
List of 2 downstream interfaces
1: GigabitEthernet0/2
2: GigabitEthernet0/3
Table 93 Output description
Field Descri
p
tion
Multicast routing table of
VPN-Instance: public net
Multicast routing table for the public network
Total 1 entry Total number of (S, G) entries in the multicast routing table
00001 Sequence number of the (S, G) entry
(172.168.0.2, 227.0.0.1) An (S, G) entry of the multicast forwarding table
Uptime
Length of time for which the (S, G) entry has been up, in
hours:minutes:seconds
Upstream interface
Upstream interface the (S, G) entry: multicast packets should arrive at
this interface
List of 2 downstream interfaces
Downstream interface list: these interfaces need to forward multicast
packets
display multicast routing-table static
Syntax
display multicast routing-table static [ config ] [ source-address { mask-length | mask } ]
View
Any view
Default level
1: Monitor level
Parameters
config: Displays the configuration information of static routes.
source-address: Multicast source address.
mask: Mask of the multicast source address.
mask-length: Mask length of the multicast source address, in the range of 0 to 32.
