Description
Use the display multicast routing-table static command to view the information of multicast static routes.
Examples
# View all the multicast static routes in the public instance.
<Sysname> display multicast routing-table static
Multicast Routing Table of VPN-Instance: public net
Routes : 1
Mroute 10.10.0.0/16
Interface = GigabitEthernet0/1 RPF Neighbor = 2.2.2.2
Matched routing protocol = <none>, Route-policy = <none>
Preference = 1, Order = 1
Running Configuration = ip rpf-route-static 10.10.0.0 16 2.2.2.2 order 1
# View the configuration information of multicast static routes in the public instance.
<Sysname> display multicast routing-table static config
Multicast Routing Table of VPN-Instance: public net
Routes : 1
Mroute 10.10.0.0/16, RPF neighbor = 2.2.2.2
Matched routing protocol = <none>, Route-policy = <none>
Preference = 1, Order = 1
Table 94 Output description
Field Descri
p
tion
Multicast Routing Table of
VPN-Instance: public net
Multicast routing table for the public network
Mroute Multicast route source address and its mask length
Interface Outgoing interface to the multicast source
RPF Neighbor
IP address of the RPF neighbor through which the multicast source is
reachable
Matched routing protocol
If a protocol is configured, the multicast source address of the route
should be the destination address of an entry in unicast routing table.
Route-policy
Routing policy. The multicast source address of the route should match
the routing policy.
Preference Route preference
Order Sequence number of the route
display multicast rpf-info
Syntax
display multicast rpf-info source-address [ group-address ]
View
Any view
