403
Table 100 Output description
Field Descri
p
tion
Routing table of VPN-Instance: public net Public network IGMP routing table
00001 Sequence number of this (*, G) entry
(*, 225.1.1.1) A (*, G) entry of the IGMP routing table
Flag
IGMP route flags:
• ACT: Indicates IGMP routing entries that have been used
for forwarding data packets but have the multicast group
address out of the SSM group range
• SUC: Indicates IGMP routing entries that have been
added to the forwarding table and have the multicast
group address within the SSM group range
List of 1 downstream interface
Downstream interface list, namely the interfaces to which
multicast data for this group will be forwarded
in include mode The downstream interface is in the include mode
in exclude mode The downstream interface is in the exclude mode
Downstream interface is none No downstream interfaces exist
Protocol Protocol type
display igmp ssm-mapping
Syntax
display igmp ssm-mapping group-address
View
Any view
Default level
1: Monitor level
Parameters
group-address: Specifies a multicast group by its IP address, in the range of 224.0.1.0 to
239.255.255.255.
Description
Use the display igmp ssm-mapping command to view the configured IGMP SSM mappings for the
specified multicast group.
Related commands: ssm-mapping.
Examples
# View the IGMP SSM mappings for multicast group 232.1.1.1 in the public instance.
<Sysname> display igmp ssm-mapping 232.1.1.1
VPN-Instance: public net
Group: 232.1.1.1
Source list:
1.2.3.4
