28
Information request: 0
Information reply: 0
Netmask request: 0
Netmask reply: 0
Unknown type: 0
Table 6 Output description
Field Descri
p
tion
current state
Current physical state of the interface:
• Administrative DOWN—The interface is shut down with the
shutdown command.
• DOWN—The interface is administratively up but its physical state is
down, which may be caused by a connection or link failure.
• UP—Both the administrative and physical states of the interface are
up.
Line protocol current state
Current state of the link layer protocol:
• DOWN—The protocol state of the interface is down, which is
usually because that no IP address is assigned to the interface.
• UP—The protocol state of the interface is up.
• UP (spoofing)—The protocol state of the interface pretends to be up;
however, no corresponding link is present, or the corresponding link
is not present permanently but is established as needed.
Internet Address
IP address of an interface followed by:
• Primary—Identifies a primary IP address.
• Sub—Identifies a secondary IP address.
• Negotiated—Identifies a PPP negotiated IP address.
• Unnumbered—Identifies an unnumbered IP address.
• Acquired via DHCP—Identifies an IP address obtained through
DHCP.
• Acquired via BOOTP—Identifies an IP address obtained through
BOOTP.
• Cluster—Identifies a cluster IP address.
• Mad—Identifies a MAD IP address.
Broadcast address Broadcast address of the subnet attached to an interface.
The Maximum Transmit Unit Maximum transmission units on the interface, in bytes.
input packets, bytes, multicasts
output packets, bytes, multicasts
Unicast packets, bytes, and multicast packets received on an interface
(the statistics start at the device startup).
ARP packet input number:
Request packet:
Reply packet:
Unknown packet:
Total number of ARP packets received on the interface (the statistics
start at the device startup:
• ARP request packets
• ARP reply packets
• Unknown packets
TTL invalid packet number
Number of TTL-invalid packets received on the interface (the statistics
start at the device startup).
