Related commands: display multicast routing-table.
Examples
# View the content of the PIM routing table in the public instance.
<Sysname> display pim routing-table
VPN-Instance: public net
Total 0 (*, G) entry; 1 (S, G) entry
(172.168.0.12, 227.0.0.1)
RP: 2.2.2.2
Protocol: pim-sm, Flag: SPT LOC ACT
UpTime: 02:54:43
Upstream interface: GigabitEthernet 0/1
Upstream neighbor: NULL
RPF prime neighbor: NULL
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet 0/2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
Table 111 Output description
Field Descri
p
tion
VPN-Instance: public net Public instance
Total 0 (*, G) entry; 1 (S, G) entry Number of (S,G) and (*, G) entries in the PIM routing table
(172.168.0.2, 227.0.0.1) An (S, G) entry in the PIM routing table
Protocol PIM mode, PIM-SM or PIM-DM
Flag Flag of the (S, G) or (*, G) entry in the PIM routing table
Uptime
Length of time for which the (S, G) or (*, G) entry has been
existing
Upstream interface Upstream (incoming) interface of the (S, G) or (*, G) entry
Upstream neighbor Upstream neighbor of the (S, G) or (*, G) entry
RPF prime neighbor
RPF neighbor of the (S, G) or (*, G) entry
• For a (*, G) entry, if this router is the RP, the RPF neighbor of
this (*, G) entry is NULL.
• For a (S, G) entry, if this router directly connects to the
multicast source, the RPF neighbor of this (S, G) entry is NULL.
Downstream interface(s) information
Information of the downstream interface(s), including:
• Number of downstream interfaces
• Downstream interface name
• Protocol type on the downstream interface(s)
• Uptime of the downstream interface(s)
• Expiry time of the downstream interface(s)
