Count of RPF check failure: 0
Incoming/outgoing SA messages: 0/0
Incoming/outgoing SA requests: 0/0
Incoming/outgoing SA responses: 0/0
Incoming/outgoing data packets: 0/0
Table 114 Output description
Field Descri
p
tion
MSDP Peer Information of
VPN-Instance: public net
Information of the MSDP peer of the public network
MSDP Peer MSDP peer address
AS
Number of the AS where the MSDP peer is located. “?” indicates that the
system was unable to obtain the AS number.
State
MSDP peer status:
• Up: Session set up; MSDP peer in session
• Listen: Session set up; local device as server, in listening state
• Connect: Session not set up; local device as client, in connecting state
• Shutdown: Deactivated
• Down: Connection failed
Resets Number of times the MSDP peer connection is reset
Up/Down time Length of time since MSDP peer connection was established/failed
Connection interface
Interface and its IP address used for setting up a TCP connection with the
remote MSDP peer
Number of sent/received
messages
Number of SA messages sent and received through this connection
Number of discarded output
messages
Number of discarded outgoing messages
Elapsed time since last connection
or counters clear
Time passed since the information of the MSDP peer was last cleared
Information about (Source,
Group)-based SA filtering policy
SA message filtering list information
• Import policy: Filter list for receiving SA messages from the specified
MSDP peer
• Export policy: Filter list for forwarding SA messages from the specified
MSDP peer
Information about SA-Requests
SA requests information
• Policy to accept SA-Request messages: Filtering rule for receiving or
forwarding SA messages from the specified MSDP peer
• Sending SA-Requests status: Whether enabled to send an SA request
message to the designated MSDP peer upon receiving a new Join
message
Minimum TTL to forward SA with
encapsulated data
Minimum TTL of multicast packet encapsulated in SA messages
SAs learned from this peer Number of cached (S, G) entries learned from this MSDP peer
SA-cache maximum for the peer
Maximum number of (S, G) entries learned from this MSDP peer that the
device can cache
