Field Description
Port Edged
The port is an edge port or non-edge port.
• Config—Configured value.
• Active—Actual value.
Point-to-point
The port is connected to a point-to-point link or not.
• Config—Configured value.
• Active—Actual value.
Transmit Limit The maximum number of packets sent within each hello time.
Protection Type
Protection type on the port:
• Root—Root guard.
• Loop—Loop guard.
• BPDU—BPDU guard.
• BPDU/ROOT—BPDU guard and root guard.
• None—No protection.
MST BPDU Format
Format of the MST BPDUs that the port can send, which can be legacy or 802.1s.
• Config—Configured value.
• Active—Actual value.
Port Config-
Digest-Snooping
The status of Digest Snooping on the port.
Rapid transition The port rapidly transitions to the forwarding state or not in the MSTI or VLAN.
Num of Vlans Mapped The number of VLANs mapped to the MSTI.
PortTimes
Major parameters for the port:
• Hello—Hello timer.
• MaxAge—Max Age timer.
• FWDly—Forward delay timer.
• MsgAge—Message Age timer.
• RemHop—Remaining hops.
BPDU Sent Statistics on sent BPDUs.
BPDU Received Statistics on received BPDUs.
MSTI RegRoot/IRPC MSTI regional root/internal path cost.
MSTI RootPortId MSTI root port ID.
MSTI Root Type MSTI root type, which can be primary root or secondary root.
Master Bridge MSTI root bridge ID.
Cost to Master Path cost from the MSTI to the master bridge.
TC received Number of received TC BPDUs.
Protocol Status Spanning tree protocol status.
Protocol Std. Spanning tree protocol standard.
Version Spanning tree protocol version.
Bridge-Prio. In MSTP mode, this field indicates the device’s priority in the CIST.
Max age(s) Aging timer (in seconds) for BPDUs.
Forward delay(s) Port state transition delay (in seconds).
