Static route configuration
Static routes are manually configured. If a network’s topology is simple, you only need to configure static
routes to implement network communication. The proper configuration and usage of static routes can
improve network performance and ensure bandwidth for important network applications.
The disadvantage of using static routes is that they cannot adapt to network topology changes. If a fault
or a topological change occurs in the network, the routes will be unreachable. The network administrator
has to modify the static routes manually.
Configuring static route in the web interface
Select Network > Static Routing from the navigation tree to enter the static route configuration page, as
shown in Figure 69. C
lick Add to enter the static route configuration page, as shown in Figure 70.
Figure 69 Static route configuration page
Figure 70 Create a static route
Table 19 Static route configuration items
Item Remarks
Destination IP Address Type the destination IP address in dotted decimal notation
Mask Specify the destination IP address mask
Next Hop Type the next hop IP address in dotted decimal notation
Outbound Interface Specify the outbound interface
