120
Table 21 RIP global configuration items
Item Descri
p
tion
Enable RIP (enable all interfaces automatically) Enable RIP on all interfaces.
Import static routes Configure RIP to redistribute static routes.
Return to RIP configuration task list.
Configuring interface RIP
Select Network > RIP from the navigation tree to enter the RIP configuration page. If RIP is enabled, the
More button is displayed. Click More to display the hidden RIP interface list, as shown in Figure 75. T
hen,
click the icon to enter the configuration page of the specified RIP interface, as shown in Figure 76.
Figure 75 Interface confi
guration page
Figure 76 RIP interface configuration page
Table 22 RIP interface configuration items
Item Descri
p
tion
Interface Displays the RIP interface name
