R3204P16-HP Load Balancing Module Network Management Configuration Guide-6PW101

125
Task Remarks
Configuring OSPF interfaces
Optional
Configure timers and OSPF authentication parameters on
the OSPF interface.
IMPORTANT:
To prevent leakage of routing information and guard
against attacks to OSPF routers, OSPF provides the packet
authentication function. To establish neighboring
relationship with a router, an OSPF router sends packets
containing the preconfigured password for authentication.
OSPF only receives packets that pass authentication, so
failed packets cannot establish neighboring relationships.
Displaying OSPF interface information Optional
Displaying OSPF neighbor information Optional
Configuring OSPF globally
Select Network > OSPF from the navigation tree to enter the OSPF configuration page, as shown
in Figure 81.
Figure 81 OSPF global c
onfiguration page
Table 24 OSPF global configuration items
Item Descri
p
tion
Enable OSPF Enable OSPF.
Import static routes Configure OSPF to redistribute static routes.
Return to OSPF configuration task list.
Configuring OSPF areas
Select Network > OSPF from the navigation tree to enter the OSPF configuration page. After you enable
OSPF, the page shown in Figure 82 is
displayed. Click Add on the Area Configuration tab to enter the
OSPF area configuration page, as shown in Figure 83.
