BGP configuration

NOTE:

The LB module supports configuring BGP only in the web interface.

The three early BGP versions are BGP-1 (RFC 1105), BGP-2 (RFC 1163), and BGP-3 (RFC 1267). The

current version in use is BGP-4 (RFC 4271), which is the defacto Internet exterior gateway protocol used

between ISPs.

Configuration prerequisites

Configure the link layer protocol and IP addresses for interfaces so that neighboring nodes can

communicate with each other.

Configuration overview

Complete the following tasks to configure BGP:

Table 29 BGP configuration task list

Task Remarks

Enable BGP

Configuring BGP

globally

Required

Enable BGP and specify an AS number.

Import static routes

Configuring BGP

globally

Optional

Configure BGP to redistribute static routes.

Configuring BGP peer

Required

Configure the IP address and AS number for the BGP peer.

Displaying BGP peer information

Optional

Display the IP address, AS number, version and current

state of the BGP peer.

Configuring BGP globally

Select Network > BGP from the navigation tree to enter the BGP configuration page, as shown in Figure

95.
