139
Figure 97 Create a BGP peer
Table 31 BGP peer configuration items
Item Descri
p
tion
Peer IP Address Configure the IP address of the BGP peer.
Peer AS Specify the AS number of the BGP peer.
Return to BGP configuration task list.
Displaying BGP peer information
Select Network > BGP from the navigation tree to enter the BGP configuration page. After you complete
BGP peer configurations, click Show Peer on the Show Information tab to display the BGP peer
information on the page shown in Figure 98.
Figure 98 Display BGP
peer information
Table 32 BGP peer information
Item Descri
p
tion
Peer IP Address IP address of the BGP peer.
Peer AS AS number of the BGP peer.
Version BGP version.
State Current state of the BGP peer.
Return to BGP configuration task list.
