R3204P16-HP Load Balancing Module Network Management Configuration Guide-6PW101

145
Figure 104 Policy configuration page
Figure 105 Create a policy
Table 33 Policy configuration items
Item Remarks
Policy Name
Type a policy name.
TIP:
Any spaces entered at the beginning or end of a policy name will be ignored. A policy
name containing only spaces is considered as null.
Node Index
Type a node index of the policy.
The node with a smaller number has a higher priority and is matched first.
Matching Mode
Select a matching mode for the node.
• permit: If a packet satisfies all the criteria defined by the if-match clauses, the
packet is permitted and the apply clauses are executed. Otherwise, the packet will
go to the next policy node for a match.
• deny: When a packet satisfies all the criteria defined by if-match clauses on the
policy node, the packet is rejected and will not go to the next policy node.
