153
Configuring the static name resolution table
Perform the tasks in Table 37 to configure the static name resolution table.
Table 37 Static name resolution table configuration task list
Task Remarks
Configuring static domain name
resolution entries
Required
Configure static domain name resolution entries, that is, mappings
between host name and IP address.
By default, no static domain name resolution entry is created.
You can configure up to 50 static domain name resolution entries.
Configuring dynamic domain name resolution
Perform the tasks in Table 38 to configure dynamic domain name resolution.
Table 38 Dynamic domain name resolution configuration task list
Task Remarks
Configuring dynamic domain name resolution
Required
Enable dynamic domain name resolution.
This function is disabled by default.
Configuring DNS server addresses
Required
Not configured by default.
You can configure up to six domain name servers.
Configuring domain name suffixes
Optional
Not configured by default.
You can configure up to ten domain name suffixes.
Configuring the DNS proxy
Perform the tasks in Table 39 to configure the DNS proxy.
Table 39 DNS proxy configuration task list
Task Remarks
Configuring the DNS proxy
Required
Configure the LB module as a DNS proxy.
By default, the LB module is not a DNS proxy.
Configuring DNS server addresses
Required
Not configured by default.
You can configure up to six domain name servers.
Configuring static domain name resolution entries
Select Network > DNS > Static from the navigation tree to enter the static domain name resolution
configuration page, as shown in Figure 111. C
lick Add to enter the page shown in Figure 112.
