155
Figure 113 Dynamic domain name resolution configuration page
Table 41 Dynamic domain name resolution configuration items
Item Descri
p
tion
Dynamic DNS Enable or disable dynamic domain name resolution.
Clear Dynamic DNS cache Remove all the information from the dynamic DNS cache.
Return to Dynamic domain name resolution configuration task list.
Configuring the DNS proxy
Select Network > DNS > Dynamic from the navigation tree to enter the page as shown in Figure 113 .
Table 42 DNS proxy configuration items
Item Descri
p
tion
DNS proxy Enable or disable DNS proxy on the LB module.
Return to DNS proxy configuration task list.
Configuring DNS server addresses
Select Network > DNS > Dynamic from the navigation tree to enter the page as shown in Figure 113 .
Click Add IP to enter the page shown in Figure 114 .
