156
Figure 114 Configure a DNS server address
Table 43 DNS server address configuration items
Item Descri
p
tion
DNS Server IP Address Type the IP address of a DNS server.
Return to Dynamic domain name resolution configuration task list.
Return to DNS proxy configuration task list.
Configuring domain name suffixes
Select Network > DNS > Dynamic from the navigation tree to enter the page as shown in Figure 113 .
Click Add Suffix to enter the page shown in Figure 115 .
Figure 115 Configure a DNS domain name suffix
Table 44 Domain name suffix configuration items
Item Descri
p
tion
DNS Domain Name Suffix Type a domain name suffix.
Return to Dynamic domain name resolution configuration task list.
Dynamic domain name resolution configuration example
Network requirements
• The IP address of the DNS server is 2.1.1.2/16 and the domain name suffix is com.
• The LB module serving as a DNS client uses dynamic domain name resolution to access the host
with the domain name host.com and the IP address 3.1.1.1/16, as shown in Figure 116.
