Figure 116 Network diagram for dynamic domain name resolution
Configuration procedure
NOTE:
• Before performing the following configuration, make sure that the LB module and the host are reachable
to each other, and related configurations are done on both the LB module and the host. For the IP
addresses of the interfaces, see Figure 116 .
• Th
is configuration may vary with different DNS servers. The followin
g
confi
g
uration is performed on a
PC running Windows server 2000.
1. Configure the DNS server
# Enter the DNS server configuration page.
Select Start > Programs > Administrative Tools > DNS.
# Create zone com.
As shown in Figure 117, r
ight click Forward Lookup Zones, select New zone, and then follow the
instructions to create a new zone named com.
Figure 117 Create a zone
# Create a mapping between host name and IP address.
