Reply from 172.16.2.2: bytes=56 Sequence=4 ttl=255 time=26 ms

Reply from 172.16.2.2: bytes=56 Sequence=5 ttl=255 time=26 ms

--- 172.16.2.2 ping statistics ---

5 packet(s) transmitted

5 packet(s) received

0.00% packet loss

round-trip min/avg/max = 25/25/26 ms

The output information shows that LB can communicate with the hosts on subnet 172.16.2.0/24.

# Ping a host on subnet 172.16.1.0/24 from a host on subnet 172.16.2.0/24 to check the connectivity.

Host B can be successfully pinged from Host A.

Displaying and maintaining IP addressing

To do… Use the command…

Remarks

Display information about a

specified or all Layer 3 interfaces

display ip interface [ interface-type

interface-number ]

Available in any view

Display brief information about a

specified or all Layer 3 interfaces

display ip interface brief [ interface-type

[ interface-number ] ]

Available in any view
