Configuring a MAC address table in the web
Adding a MAC address entry
Select Network > MAC > MAC from the navigation tree to enter the MAC address entry list page, as
shown in Figure 9.
Figure 9 MAC address entry list page
Click Add to enter the MAC address entry adding page, as shown in Figure 10.
Figure 10 Add a MAC address entry
Table 4 Configuration items for adding a MAC address entry
Item Descri
p
tion
MAC Type the MAC address you want to add.
Type
Set the type of the MAC address entry:
• Static—Static MAC address entries that never age out.
• Dynamic—Dynamic MAC address entries that will age out.
• Blackhole—Blackhole MAC address entries that never age out.
IMPORTANT:
The tab displays the following types of MAC address entries:
• Config static—Static MAC address entries manually configured by the users.
• Config dynamic—Dynamic MAC address entries manually configured by the
users.
• Blackhole—Blackhole MAC address entries.
• Learned—Dynamic MAC address entries learned by the LB module.
• Other—Other types of MAC address entries.
