33
To do… Use the command…
Remarks
Configure the link type of the
Ten-GigabitEthernet interface as
trunk
port link-type trunk Required
Assign the trunk port to the
specified VLANs
port trunk permit vlan
{ vlan-id-list | all }
Required
The VLAN of the LB module and the
VLANs of the subinterfaces of the
Ten-GigabitEthernet interface must be
included.
Create a subinterface of the
Ten-GigabitEthernet interface and
enter subinterface view
interface Ten-GigabitEthernet
interface-number.subnumber
Required
The subnumber must be one of the VLAN
IDs created on the switch.
Configure the operating mode of
the subinterface as Layer 2
port link-mode bridge Required
Configure the link type of the
subinterface as access
port link-type access
Optional
By default, the link type of a subinterface
is access.
Assign the subinterface to the
VLAN of the LB module
port access vlan vlan-id Required
Create another subinterface and
enter subinterface view
interface Ten-GigabitEthernet
interface-number.subnumber
Required
The subnumber must be the ID of the
other VLAN created on the switch.
Configure the operating mode of
the subinterface as Layer 2
port link-mode bridge Required
Configure the link type of the
subinterface as access
port link-type access
Optional
By default, the link type of a subinterface
is access.
Assign the subinterface to the
VLAN of the LB module
port access vlan vlan-id Required
Displaying and maintaining inter-VLAN Layer 2 forwarding
To do… Use the command…
Remarks
Display brief interface
information
display brief interface [ interface-type [ interface-number
| interface-number.subnumber ] ] [ | { begin | include |
exclude } text ]
Available in any
view
Display
interface/subinterface state
and related information
display interface [ interface-type [ interface-number |
interface-number.subnumber ] ]
Available in any
view
Clear the
interface/subinterface
statistics
reset counters interface [ interface-type
[ interface-number | interface-number.subnumber ] ]
Available in any
view
Reset an Ethernet
interface/subinterface
reset port interface-type { interface-number |
interface-number.subnumber }
Available in any
view
