34
To do… Use the command…
Remarks
Display VLAN information
display vlan [ vlan-id1 [ to vlan-id2 ] | all | dynamic |
interface interface-type interface-number.subnumber |
reserved | static ]
Available in any
view
Forward-type inline Layer 2 forwarding
configuration example
Network requirements
Configure forward-type inline Layer 2 forwarding between Ten-GigabitEthernet 0/0.1 and
Ten-GigabitEthernet 0/0.2. Then packets received on Ten-GigabitEthernet 0/0.1 can be forwarded
through Ten-GigabitEthernet 0/0.2 directly, and vice versa.
Configuration procedure
# Create forward-type inline Layer 2 forwarding entry 1.
<Sysname> system-view
[Sysname] inline-interfaces 1
# Assign Ten-GigabitEthernet 0/0.1 to forward-type inline Layer 2 forwarding entry 1.
[Sysname] interface Ten-GigabitEthernet 0/0.1
[Sysname-Ten-GigabitEthernet0/0.1] port inline-interfaces 1
# Assign Ten-GigabitEthernet 0/0.2 to forward-type inline Layer 2 forwarding entry 1.
[Sysname-Ten-GigabitEthernet0/0.1] interface Ten-GigabitEthernet 0/0.2
[Sysname-Ten-GigabitEthernet0/0.2] port inline-interfaces 1
Blackhole-type inline Layer 2 forwarding
configuration example
Network requirements
Configure blackhole-type inline Layer 2 forwarding on Ten-GigabitEthernet 0/0.1. Then packets received
on Ten-GigabitEthernet 0/0.1 are directly dropped.
Configuration Procedure
# Create blackhole-type inline Layer 2 forwarding entry 1.
<Sysname> system-view
[Sysname] inline-interfaces 1 blackhole
# Assign Ten-GigabitEthernet 0/0.1 to blackhole-type inline Layer 2 forwarding entry 1.
[Sysname] interface Ten-GigabitEthernet 0/0.1
[Sysname-Ten-GigabitEthernet0/0.1] port inline-interfaces 1
