Port type

Actions (in the inbound direction)

Actions (in the outbound

direction)

Unta

ed frame Ta

ed frame

Trunk

Checks whether the

PVID is permitted on

the port:

• If yes, tags the

frame with the

PVID tag.

• If not, drops the

frame.

• Receives the frame if its VLAN is

carried on the port.

• Drops the frame if its VLAN is not

carried on the port.

• Removes the tag and sends

the frame if the frame

carries the PVID tag and

the port belongs to the

PVID.

• Sends the frame without

removing the tag if its

VLAN is carried on the port

but is different from the

PVID.

Hybrid

Sends the frame if its VLAN is

carried on the port. The frame

is sent with the VLAN tag

removed or intact depending

on your configuration.

Configuring a VLAN in the web

Configuration task list

Perform the tasks in Table 6 to configure a VLAN.

Table 6 VLAN configuration task list

Task Remarks

Creating a VLAN Required

Modifying a VLAN

Required

Select either task.

Configure the untagged and tagged member ports of

the VLAN, or remove ports from the VLAN.

Modifying a port

Creating a VLAN

Select Network > VLAN > VLAN from the navigation tree to enter the page as shown in Figure 20.
