To do… Use the command Remarks
Assign an IP address to the
subinterface
ip address ip-address { mask |
mask-length } [ sub ]
Required
By default, no IP address is
configured for the subinterface.
Create another subinterface and
enter subinterface view
interface Ten-GigabitEthernet
interface-number.subnumber
Required
Set the encapsulation type and
associate the subinterface with a
VLAN
vlan-type dot1q vid vid
Optional
The subinterface receives packets
with the vid.
Assign an IP address to the
subinterface
ip address ip-address { mask |
mask-length } [ sub ]
Required
By default, no IP address is
configured for the subinterface.
Displaying and maintaining Layer 3 subinterface forwarding
To do… Use the Command Remarks
Display brief interface
information
display brief interface [ interface-type [ interface-number
| interface-number.subnumber ] ] [ | { begin | include |
exclude } text ]
Available in any
view
Display
interface/subinterface state
and related information
display interface [ interface-type [interface-number |
interface-number.subnumber ] ]
Available in any
view
Clear interface/subinterface
statistics
reset counters interface [ interface-type [ interface-number
| interface-number.subnumber ] ]
Available in user
view
Configuring inter-VLAN Layer 3 forwarding
NOTE:
For more information about inter-VLAN forwarding configuration commands, see
Network Mana
g
emen
t
Command Reference .
Configuring inter-VLAN Layer 3 forwarding
Perform the following configurations to achieve inter-VLAN Layer 3 forwarding.
1. Configure the ports of the switch
• Create two VLANs. Assign the ingress port to one VLAN and the egress port to the other.
• Configure the switch’s ten-GigabitEthernet port that connects to the LB module as a trunk port and
configure the trunk port to join these two VLANs.
2. Configure the LB module
• Create two VLANs, in which packets from the switch are forwarded.
• Configure the operating mode of the ten-GigabitEthernet interface that connects to the switch as
Layer 2 mode, and configure the link type as trunk. Assign the interface to the two VLANs created
on the switch.
