• Create two VLAN interfaces with the same numbers as VLANs created on the switch for the
ten-GigabitEthernet interface.
• Assign IP addresses for the two VLAN interfaces.
NOTE:
To achieve Layer 3 forwarding between VLANs, you can create these VLANs on the switch and confi
g
ure
the same number of VLAN interfaces for the ten-GigabitEthernet interface on the LB module.
Configure the ports of the switch
Follow these steps to configure the ports of the switch:
To do… Use the command
Remarks
Enter system view system-view —
Create a VLAN and enter VLAN view vlan vlan-id Required
Assign the access port(s) to the VLAN port interface-list
Required
By default, all ports belong to VLAN 1.
Create another VLAN and enter VLAN
view
vlan vlan-id Required
Assign the access port(s) to the VLAN port interface-list
Required
By default, all ports belong to VLAN 1.
Enter the view of the ten-GigabitEthernet
interface that connects to the LB module
interface
Ten-GigabitEthernet
interface-number
Required
Configure the link type of the interface
as trunk
port link-type trunk Required
Assign the trunk port to the two VLANs
port trunk permit vlan
{ vlan-id-list | all }
Required
Configure the default VLAN for the trunk
port
port trunk pvid vlan
vlan-id
Optional
The default VLAN cannot be one of the
previously configured two VLANs.
Configure the LB module
Follow these steps to configure the LB module:
To do… Use the command…
Remarks
Enter system view system-view —
Create two VLANs and enter VLAN
view.
vlan vlan-id Required
Exit to system view quit —
Enter the view of the
ten-GigabitEthernet interface that
connects to the switch
interface
Ten-GigabitEthernet
interface-number
Required
Configure the operating mode of
the interface as Layer 2
port link-mode bridge
Required
The default operating mode is Layer 3.
