Table 11 Static NAT configuration task list
Task Remarks
Creating a static address mapping
Required
Static NAT supports two modes, one-to-one and net-to-net.
Enabling static NAT on an interface
Required
Configure static NAT on an interface.
Configuring an internal server
Perform the tasks in Table 12 to configure an internal server.
Table 12 Internal server configuration task list
Task Remarks
Creating an internal server
Required
After you map the private IP address/port number of an internal server to a
public IP address/port number, hosts in external networks can access the
server located in the private network.
Configuring a DNS mapping
Optional
The DNS mapping feature enables an internal host to use the domain name
to access an internal server located on the same private network, while the
DNS server resides on the public network.
Creating an address pool
Select Security > NAT > Dynamic NAT from the navigation tree to enter the page shown in Figure 43. In
the Address Pool field where all NAT address pools are displayed, click Add to enter the Add NAT
Address Pool page shown in Figure 44.
