R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

120
Ste
p
Command Remarks
2. Assign an IP address of a
global address pool for the
peer or specify the IP
address to be allocated to
the peer.
• (Approach 1) Define a global
address pool and bind it to the
interface:
a. ip pool pool-number
low-ip-address
[ high-ip-address ]
b. interface virtual-template
number
c. remote address pool
[ pool-number ]
• (Approach 2) Specify the IP address
to be allocated to the peer:
a. interface virtual-template
number
b. remote address ip-address
Use either approach.
As for the remote address pool
command, if the pool-number
argument is not provided, the
global address pool numbered
0 is used.
To configure the local end as the server (for cases where PPP authentication is enabled):
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter domain view. domain domain-name N/A
3. Define the domain address
pool.
ip pool pool-number low-ip-address
[ high-ip-address ]
N/A
4. Return to system view.
quit N/A
5. Create a VT interface and
enter its view.
interface virtual-template number N/A
6. Specify the address pool for
IP address allocation.
remote address pool
[ pool-number ]
If you execute the remote address
pool command without providing
the pool-number argument, all the
address pools in the domain are
used in turn for IP address
allocation.
7. Disable the peer end from
using the locally configured IP
address.
ppp ipcp remote-address forced
Optional.
By default, the peer end is allowed
to use the locally configured IP
address. In this case, the local end
does not allocate an IP address to
the peer end if the latter already
has an IP address.
Note that the domain used in defining the pool address is the domain specified when performing PPP
authentication.
Configuring DNS server address negotiation
Configure DNS server settings depending on the role of your device in PPP negotiation.
