Figure 72 Dialer interface information
Configuring the PPPoE client at the CLI
PPPoE client configuration includes dialer interface configuration and PPPoE session configuration.
Configuring a dialer interface
Before establishing a PPPoE session, you must first create a dialer interface and configure a dialer bundle
on the interface. Each PPPoE session uniquely corresponds to a dialer bundle and each dialer bundle
uniquely corresponds to a dialer interface. A PPPoE session uniquely corresponds to a dialer interface.
Configuring a dialer interface for an IPv4 PPPoE client
Ste
p
Command
1. Enter system view. system-view
2. Configure a dialer rule.
dialer-rule dialer-group { protocol-name { permit | deny } | acl
acl-number }
3. Create a dialer interface.
interface dialer number
4. Create a dialer user.
dialer user username
5. Assign an IP address to the interface. ip address { address mask | ppp-negotiate }
6. Associate the interface with a dialer
bundle.
dialer bundle bundle-number
7. Assign the interface to a dialer group. dialer-group group-number
