Creating a blackhole-type inline forwarding policy
NOTE:
Before configuration, make sure that GigabitEthernet 0/1 operates in brid
g
e mode and it is added to a
zone.
• Select Network > Forwarding from the navigation tree. On the page, click Add to enter the page
for adding an inline forwarding policy.
Figure 77 Adding a blackhole-type inline forwarding policy
• Enter policy ID 1.
• Select Blackhole as the policy type.
• Select GigabitEthernet0/1 from the Port 1 list.
• Click Apply.
Configuring inline forwarding at the CLI
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Configure an inline Layer 2
forwarding entry.
inline-interfaces id [ blackhole |
reflect ]
N/A
3. Enter Layer 2 Ethernet
interface view.
interface interface-type
interface-number
N/A
4. Assign an interface to the
inline Layer 2 forwarding
entry.
port inline-interfaces id
By default, the interface does not belong
to any inline Layer 2 forwarding entry.
Two interfaces must be assigned to the
forward-type inline forwarding entry
while one interface is required for the
reflect or blackhole type.
