• RFC 2132, DHCP Options and BOOTP Vendor Extensions
• RFC 1542, Clarifications and Extensions for the Bootstrap Protocol
Configuring an interface to dynamically obtain an
IP address through BOOTP
To configure an interface to dynamically obtain an IP address:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure an interface to
dynamically obtain an IP
address through BOOTP.
ip address bootp-alloc
By default, an interface does not
use BOOTP to obtain an IP
address.
Displaying and maintaining BOOTP client
configuration
Task Command Remarks
Display BOOTP client information.
display bootp client [ interface interface-type
interface-number ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
BOOTP client configuration example
Network requirements
As shown in Figure 119, GigabitEthernet 0/1 of the Firewall connect to the LAN to obtain an IP address
from the DHCP server by using BOOTP.
