Task Remarks
Applying the policy to an interface
Required.
Apply the QoS policy to the specified interface.
CAUTION:
• With CBQ configured on an interface, you can set the maximum available interface bandwidth, which
can be used for bandwidth check when CBQ enqueues packets. For more information, see
"Configuring port bandwidth limit." On tunn
el
interfaces, sub-interfaces, or VT/dialer interfaces usin
g
PPPoE, PPPoA, PPPoEoA, or PPPoFR encapsulation, you must configure the maximum available interface
bandwidth to provide base bandwidth for CBQ bandwidth calculation.
• For CBQ to take effect on a tunnel interface, sub-interface, or VT/dialer interface usin
g
PPPoE, PPPoA,
PPPoEoA, or PPPoFR encapsulation, you must enable line rate on the interface. For more information, see
"Configuring line rate on a port."
Configuring a class
To configure a class, create it first, and then configure classification rules for it.
1. Create a class
Select Firewall > QoS > Classifier from the navigation tree to enter the classifier displaying page, as
shown in Figure 175. T
hen
click Add to enter the page for creating a class, as shown in Figure 176.
Figure 175 Classes
