Figure 176 Creating a class
Table 47 Configuration items
Item Descri
p
tion
Classifier Name Specify a name for the classifier to be created.
Operation Type
Specify the logical relationship between rules in the classifier. The following options
are available:
• And—Specifies the relationship between the rules in a class as logical AND. The
firewall considers a packet as belonging to a class only when the packet matches all
the rules in the class.
• Or—Specifies the relationship between the rules in a class as logical OR. The
firewall considers a packet as belonging to a class as long as the packet matches
one of the rules in the class.
2. Configure classification rules
Click the icon in the Operation column for the class to be configured on the class list to enter
the page as shown in Figure 177. On the u
pper part of the page, you c
an modify the basic
information of the class; on the lower part of the page, information about all rules of the class is
displayed. Click Create to enter the page for creating a classification rule for the class, as shown
in Figure 178.
Figure 177 Classification
rule configuration page
