R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

282
To apply the QoS policy to an interface:
Ste
p
Command
1. Enter system view.
system-view
2. Enter interface view.
interface interface-type interface-number
3. Apply the policy to the
interface.
qos apply policy policy-name { inbound | outbound }
Displaying and maintaining QoS policies
Task Command Remarks
Display traffic class configuration.
display traffic classifier
{ system-defined | user-defined }
[ tcl-name ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
Display traffic behavior
configuration.
display traffic behavior
{ system-defined | user-defined }
[ behavior-name ] [ | { begin |
exclude | include }
regular-expression ]
Available in any view
Display user-defined QoS policy
configuration.
display qos policy { system-defined
| user-defined } [ policy-name
[ classifier tcl-name ] ] [ | { begin |
exclude | include }
regular-expression ]
Available in any view
Display QoS policy configuration
on the specified or all interfaces.
display qos policy interface
[ interface-type interface-number ]
[ inbound | outbound ] [ | { begin
| exclude | include }
regular-expression ]
Available in any view
Configuring line rate on a port
Select Firewall > QoS > Line rate from the navigation tree and click the Setup tab to enter the line rate
configuration page, as shown in Figure 187.
