293
{
Select classifier_mserver on the classifier list and click its icon. Click Create, and perform
configuration on the page shown in Figure 203.
{
Select the ACL option and select ACL 3001.
{
Click Apply.
# Configure class classifier_fserver to match packets based on ACL 3002.
{
Select Firewall > QoS > Classifier from the navigation tree and then click Add. Perform
configuration on the page shown in Figure 202.
{
Enter the class name classifier_fserver.
{
Click Apply.
{
Select classifier_fserver on the classifier list and click its icon. Click Create, and perform
configuration on the page shown in Figure 203.
{
Select the ACL option and select ACL 3002.
{
Click Apply.
3.
Configure traffic behaviors:
# Configure traffic behavior behavior_dbserver to mark packets with local precedence 4.
{
Select Firewall > QoS > Behavior from the navigation tree and then click Add. Perform
configuration on the page shown in Figure 204.
Figure 204 Creating traffic behavior behavior_dbser
ver
{
Enter the behavior name behavior_dbserver.
{
Click Apply.
{
Click the icon for behavior_dbserver on the behavior list, and perform configuration on the
page shown in Figure 205.
