295
{
After OK appears, click Close.
# Configure traffic behavior behavior_mserver to mark packets with local precedence 3.
{
Select Firewall > QoS > Behavior from the navigation tree and then click Add. Perform
configuration on the page shown in Figure 204.
{
Enter the behavior name behavior_mserver.
{
Click Apply.
{
Click the icon for behavior_mserver on the behavior list, and perform configuration on the
page shown in Figure 205.
{
Select the Dot1p box, and then select 3 from its list.
{
Click Apply. The configuration progress dialog box as shown in Figure 206 appears.
{
After OK appears, click Close.
# Configure traffic behavior behavior_fserver to mark packets with local precedence value 2.
{
Select Firewall > QoS > Behavior from the navigation tree and then click Add. Perform
configuration on the page shown in Figure 204.
{
Enter the behavior name behavior_fserver.
{
Click Apply.
{
Click the icon for behavior_fserver on the behavior list, and perform configuration as
shown in Figure 205.
{
Select the Dot1p box, and then select 2 from its list.
{
Click Apply. The configuration progress dialog box as shown in Figure 206 appears.
{
After OK appears, click Close.
4.
Configure a policy:
# Create QoS policy policy_server, and configure class-behavior associations for the policy.
{
Select Firewall > QoS > Policy from the navigation tree and then click Add. Perform
configuration on the page on the page shown in Figure 207.
Figure 207 Creating policy policy_server
{
Enter the policy name policy_server.
{
Click Apply.
{
Select policy_server from the Policy Name list above the policy list and then click Add Relation.
Perform configuration on the page shown in Figure 208.
