Configuring traffic policing in the Web interface
NOTE:
Traffic policing can be configured in the policy-based approach or CAR list-based approach. This chapter
describes only how to configure traffic policing in the CAR list-based approach. For how to configure
traffic policing in the policy-based approach, see the chapter “QOS configuration.”
Configuration task list
NOTE:
Committed access rate (CAR) is the major traffic policing mechanism, and therefore this document
introduces how to configure CAR.
Table 56 Traffic policing configuration task list
Task Remarks
Creating a CAR list
Required.
Create an IP network segment-based CAR list.
Applying a CAR list to an interface
Required.
Apply the CAR policy to the specified interface.
IMPORTANT:
You can configure multiple CAR policies on an interface, and these CAR
policies are executed in the order they are configured.
Creating a CAR list
Select Firewall > Traffic Policing > CAR List from the navigation tree to enter the page displaying the CAR
lists, as shown in Figure 222. Cli
ck Add to enter the page for creating a CAR list, as shown in Figure 223.
Figure 222 CAR list
