Figure 238 RIP interface configuration page
4. Configure RIP interface as described in Table 61.
Table 61 Configuration items
Item Descri
p
tion
Interface Displays the RIP interface name
Work State
Set whether to allow the receiving/sending of RIP packets on the interface.
• On—Allows the receiving/sending of RIP packets on the interface.
• Off—Disallows the receiving/sending of RIP packets on the interface.
Version
Specify a RIP version for the interface.
• Default—Indicates the interface can send RIPv1 broadcasts and can
receive RIPv1 broadcast and unicast packets, and RIPv2 broadcast,
multicast, and unicast packets.
• RIPv1—Indicates the interface can send RIPv1 broadcasts, and can
receive RIPv1 broadcasts and RIPv1 unicasts.
• RIPv2—Indicates the interface can send RIPv2 multicasts and can
receive RIPv2 unicasts, broadcasts and multicasts.
• RIPv2 broadcast—Indicates the interface can send RIPv2 broadcasts
and can receive RIPv1 unicasts, and broadcasts, and RIPv2 broadcasts,
multicasts and unicasts.
