Command Remarks
3. Enable RIP on the interface
attached to the specified
network.
network network-address Disabled by default
NOTE:
•
If you make some RIP configurations in interface view before enabling RIP, those configurations will take effect
after RIP is enabled.
• RIP runs only on the interfaces residing on the specified networks. Specify the network after enabling RIP to
validate RIP on a specific interface.
• You can enable RIP on all interfaces using the command network 0.0.0.0.
• If a physical interface is attached to multiple networks, you cannot advertise these networks in different RIP
processes.
Configuring the interface behavior
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter RIP view.
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
N/A
3. Disable an or all interfaces from
sending routing updates (the
interfaces can still receive
updates).
silent-interface { interface-type
interface-number | all }
Optional.
All interfaces can send routing
updates by default.
4. Return to system view.
quit N/A
5. Enter interface view.
interface interface-type
interface-number
N/A
6. Enable the interface to receive
RIP messages.
rip input
Optional.
Enabled by default.
7. Enable the interface to send RIP
messages.
rip output
Optional.
Enabled by default.
Configuring a RIP version
You can configure a RIP version in RIP or interface view.
• If neither global nor interface RIP version is configured, the interface sends RIPv1 broadcasts and
can receive the following packets: RIPv1 broadcast, RIPv1 unicast, RIPv2 broadcast, RIPv2 multicast,
and RIPv2 unicast.
• If an interface has no RIP version configured, it uses the global RIP version; otherwise it uses the RIP
version configured on it.
• With RIPv1 configured, an interface sends RIPv1 broadcasts, and can receive RIPv1 broadcasts
and RIPv1 unicasts.
• With RIPv2 configured, a multicast interface sends RIPv2 multicasts and can receive RIPv2 unicasts,
broadcasts, and multicasts.
• With RIPv2 configured, a broadcast interface sends RIPv2 broadcasts and can receive RIPv1
unicasts, and broadcasts, and RIPv2 broadcasts, multicasts, and unicasts.
