R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

336
To configure a RIP version:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter RIP view.
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
N/A
3. Specify a global RIP version.
version { 1 | 2 }
Optional.
By default, if an interface has a
RIP version specified, the
version takes precedence over
the global one. If no RIP
version is specified for an
interface, the interface can
send RIPv1 broadcasts, and
receive RIPv1 broadcasts,
unicasts, RIPv2 broadcasts,
multicasts and unicasts.
4. Return to system view.
quit N/A
5. Enter interface view.
interface interface-type
interface-number
N/A
6. Specify a RIP version for the
interface.
rip version { 1 | 2 [ broadcast |
multicast ] }
Optional.
By default, if an interface has
no RIP version specified, the
global version takes effect. If
no global RIP version is
specified, the interface can
send RIPv1 broadcasts, and
receive RIPv1 broadcasts,
unicasts, RIPv2 broadcasts,
multicasts and unicasts.
Configuring RIP route control
Before you configure RIP routing feature, complete the following tasks:
• Configure an IP address for each interface, and make sure all neighboring routers can reach each
other.
• Configure RIP basic functions.
Configuring an additional routing metric
An additional routing metric (hop count) can be added to the metric of an inbound or outbound RIP
route.
The outbound additional metric is added to the metric of a sent route, and the route’s metric in the routing
table is not changed.
The inbound additional metric is added to the metric of a received route before the route is added into
the routing table, and the route’s metric is changed. If the sum of the additional metric and the original
metric is greater than 16, the metric of the route will be 16.
To configure additional routing metrics:
