Command Remarks
1. Enter system view. system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Define an inbound additional
routing metric.
rip metricin [ route-policy
route-policy-name ] value
Optional.
The default is 0.
4. Define an outbound additional
routing metric.
rip metricout [ route-policy
route-policy-name ] value
Optional.
The default is 1.
Configuring RIPv2 route summarization
Route summarization means that subnets in a natural network are summarized into a natural network that
is sent to other networks. This feature can reduce the size of routing tables.
After route summarization, the smallest metric among all the summarized routes is used as the metric of
the summary route.
• Enable RIPv2 route automatic summarization.
You can disable RIPv2 route automatic summarization if you want to advertise all subnet routes.
To enable RIPv2 route automatic summarization:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter RIP view.
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
N/A
3. Enable RIPv2 automatic route
summarization.
summary
Optional.
Enabled by default.
If the subnet routes in the
routing table are not
consecutive, disable automatic
route summarization to avoid
black hole routing.
• Advertise a summary route.
To configure RIPv2 to advertise a summary route on the specified interface:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter RIP view.
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
N/A
3. Disable RIPv2 automatic route
summarization.
undo summary Enabled by default.
4. Return to system view.
quit N/A
5. Enter interface view.
interface interface-type
interface-number
N/A
