Configuring single-hop detection in BFD echo packet mode
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Configure the source IP
address of BFD echo packets.
bfd echo-source-ip ip-address
By default, no source IP address is
configured for BFD echo packets.
3. Enter interface view.
interface interface-type
interface-number
N/A
4. Enable BFD on the RIP
interface.
rip bfd enable Disabled by default.
Configuring bidirectional detection in BFD control packet mode
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create a RIP process and
enter RIP view.
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
By default, RIP is disabled.
3. Specify a RIP neighbor.
peer ip-address
By default, RIP does not unicast
updates to any peer.
4. Enter interface view.
interface interface-type
interface-number
N/A
5. Enable BFD on the RIP
interface.
rip bfd enable Disabled by default.
NOTE:
• Unidirectional detection in BFD echo packet mode only works for RIP neighbors that are directly
connected (one hop away from each other).
• Using the undo peer command does not remove the neighbor relationship at once; therefore, it canno
t
bring down the BFD session at once.
Displaying and maintaining RIP
Task Command Remarks
Display RIP current status and
configuration informationN/A
display rip [ process-id |
vpn-instance vpn-instance-name ]
[ | { begin | exclude | include }
regular-expression ]
Available in any view
Display all active routes in RIP
databaseN/A
display rip process-id database [ |
{ begin | exclude | include }
regular-expression ]
Display RIP interface
informationN/A
display rip process-id interface
[ interface-type interface-number ]
[ | { begin | exclude | include }
regular-expression ]
