R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

381
Ste
p
Command Remarks
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure the OSPF network
type for the interface as NBMA.
ospf network-type nbma
By default, the network type of
an interface depends on the
link layer protocol.
4. Configure a router priority for
the interface.
ospf dr-priority priority
Optional.
The default router priority is 1
5. Exit to system view. quit N/A
6. Enter OSPF view.
ospf [ process-id | router-id router-id
| vpn-instance vpn-instance-name ] *
N/A
7. Specify a neighbor and its
router priority.
peer ip-address [ cost value |
dr-priority dr-priority ]
N/A
NOTE:
The router priority configured with the ospf dr-priority command and the one configured with the peer
command have the following differences.
• The former is for actual DR election.
• The latter is to indicate whether a neighbor has the election right or not. If you configure the router
priority for a neighbor as 0, the local router will assume the neighbor has no election right, and thus
send no hello packets to this neighbor. However, if the local router is the DR or BDR, it still sends hello
packets to the neighbor with priority 0 for adjacency establishment.
Configuring the OSPF network type for an interface as P2MP
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure the OSPF network
type for the interface as P2MP.
ospf network-type p2mp [ unicast ]
By default, the network type of
an interface depends on the
link layer protocol.
After you configure the OSPF
network type for an interface
as P2MP unicast, all packets
are unicast over the interface.
The interface cannot
broadcast hello packets to
discover neighbors. In that
case, you need to manually
specify the neighbors.
4. Exit to system view. quit N/A
5. Enter OSPF view.
ospf [ process-id | router-id router-id
| vpn-instance vpn-instance-name ] *
N/A
