R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

385
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter OSPF view.
ospf [ process-id | router-id router-id
| vpn-instance vpn-instance-name ] *
N/A
3. Configure a bandwidth
reference value.
bandwidth-reference value
Optional.
The value defaults to 100
Mbps.
Configuring the maximum number of OSPF routes
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter OSPF view.
ospf [ process-id | router-id router-id
| vpn-instance vpn-instance-name ] *
N/A
3. Configure the maximum number
of OSPF routes.
maximum-routes { external | inter |
intra } number
Optional.
Configuring the maximum number of ECMP routes
Perform this task to implement load sharing over ECMP routes.
To configure the maximum number of ECMP routes:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter OSPF view.
ospf [ process-id | router-id router-id
| vpn-instance vpn-instance-name ] *
N/A
3. Configure the maximum number
of ECMP routes.
maximum load-balancing maximum
Optional.
By default, the maximum
number of ECMP routes
depends on the device model,
as shown in the following
table.
All firewalls support the maximum load-balancing maximum command, and the maximum argument has
different default values:
Item F1000-A-EI/S-EI F1000-E F5000 Firewall module
Default value 8 8 16 8
Configuring OSPF preference
A router may run multiple routing protocols, and each protocol is assigned a preference. When the
routing protocols find routes to the same destination, the route found by the protocol with the highest
preference is selected as the best route.
To configure OSPF preference:
