device. Note that, when you use a loopback interface address as the source address of IP packets,
make sure that the route from the loopback interface to the peer is reachable by performing routing
configuration. All data packets sent to the loopback interface are considered as packets sent to the
device itself, so the device does not forward these packets.
• Because a loopback interface is always up, it can be used in dynamic routing protocols. For
example, if no router ID is configured for a dynamic routing protocol, the highest loopback interface
IP address is selected as the router ID. In BGP, to avoid BGP sessions being interrupted by physical
port failure, you can use a loopback interface as the source interface of BGP packets.
Configuration procedure
To configure a loopback interface:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Create a loopback interface
and enter loopback interface
view.
interface loopback
interface-number
N/A
3. Set the interface description.
description text
Optional.
By default, the description of a
loopback interface is interface name
Interface.
4. Shut down the loopback
interface.
shutdown
Optional.
By default, a loopback interface is up.
5. Restore the default settings for
the loopback interface.
default Optional.
NOTE:
You can configure settings such as IP addresses and IP routes on loopback interfaces.
Configuring the null interface
Introduction to the null interface
A null interface is a completely software-based logical interface, and is always up. However, you cannot
use it to forward data packets or configure an IP address or link layer protocol on it. With a null interface
specified as the next hop of a static route to a specific network segment, any packets routed to the
network segment are dropped. The null interface provides a simpler way to filter packets than ACL. You
can filter uninteresting traffic by transmitting it to a null interface instead of applying an ACL.
For example, by executing the ip route-static 92.101.0.0 255.255.0.0 null 0 command (which configures
a static route leading to null interface 0), you can have all the packets destined to the network segment
92.101.0.0/16 discarded.
Only one null interface, interface Null 0, is supported on your device. You cannot remove or create a null
interface.
Configuration procedure
To enter null interface view:
