R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

457
Ste
p
Command Remarks
Reset all IBGP connections. reset bgp internal
Reset all IPv4 unicast BGP
connections.
reset bgp ipv4 all
Clearing BGP information
Ste
p
Command Remarks
Clear dampened MBGP routing
information and release suppressed
routes.
reset bgp dampening [ ip-address
[ mask | mask-length ] ]
Available in user view
Clear route flap information.
reset bgp flap-info [ ip-address
[ mask-length | mask ] | as-path-acl
as-path-acl-number | regexp
as-path-regular-expression ]
BGP basic configuration at the CLI
Network requirements
In Figure 284, run EBGP between Firewall A and Firewall B and IBGP between Firewall B and Firewall
C so that Firewall C can access the network 8.1.1.0/24 connected to Firewall A.
Figure 284 Network diagram
Configuration procedure
1. Configure IP addresses for interfaces. (Details not shown)
2. Configure IBGP:
{ To prevent route flapping caused by port state changes, this example uses loopback interfaces
to establish IBGP connections.
{ Because loopback interfaces are virtual interfaces, you need to use the peer connect-interface
command to specify the loopback interface as the source interface for establishing BGP
connections.
{ Enable OSPF in AS 65009 to make sure that Firewall B can communicate with Firewall C
through loopback interfaces.
# Configure Firewall B.
<FirewallB> system-view
[FirewallB] bgp 65009
[FirewallB-bgp] router-id 2.2.2.2
