*Nov 5 11:42:24:187 2009 RouterC RM/6/RMDEBUG: BGP_BFD: Reset BGP session 3.0.1.1
for BFD session down.
*Nov 5 11:42:24:187 2009 RouterC RM/6/RMDEBUG: BGP_BFD: Send DELETE msg to BFD,
Connection type DIRECT, Src IP 3.0.2.2, Dst IP 3.0.1.1, Instance ID 0.
# Display route 1.1.1.0/24 on Router C, and you can see that Firewall A and Router C
communicate through Router D.
<RouterC> display ip routing-table 1.1.1.0 24 verbose
Routing Table : Public
Summary Count : 1
Destination: 1.1.1.0/24
Protocol: BGP Process ID: 0
Preference: 0 Cost: 100
NextHop: 2.0.1.1 Interface: GigabitEthernet0/2
BkNextHop: 0.0.0.0 BkInterface:
RelyNextHop: 2.0.2.1 Neighbor : 2.0.1.1
Tunnel ID: 0x0 Label: NULL
State: Active Adv Age: 00h09m54s
Tag: 0
The output shows that Router C has one route to reach network 1.1.1.0/24, that is, Router
C<—>Router D<—>Firewall A.
Troubleshooting BGP
BGP peer relationship not established
Symptom
Display BGP peer information by using the display bgp peer command. The state of the connection to a
peer cannot become established.
Analysis
To become BGP peers, any two routers need to establish a TCP session using port 179 and exchange
Open messages successfully.
Solution
1. Use the display current-configuration command to check that the peer’s AS number is correct.
2. Use the display bgp peer command to check that the peer’s IP address is correct.
3. If a loopback interface is used, check that the loopback interface is specified with the peer
connect-interface command.
4. If the peer is a non-direct EBGP peer, check that the peer ebgp-max-hop command is configured.
5. If the peer ttl-security hops command is configured, check that the command is configured on the
peer, and the hop-count values configured on them are greater than the number of hops between
them.
6. Check that a valid route to the peer is available.
7. Use the ping command to check the connectivity to the peer.
