Applying a policy
Select Network > Routing Management > Policy Routing from the navigation tree, and then click the
Application tab to enter the page shown in Figure 302. Cli
ck Add to enter the page where you can apply
a policy, as shown in Figure 303.
Figure 302 PBR application page
Figure 303 Applying a policy
Table 75 Configuration items
Item Descri
p
tion
Apply to
Specify the policy application mode:
• Local—Enables local PBR. Unless otherwise
required, HP does not recommend enabling local
PBR.
• Interface—Enables interface PBR. Apply the policy
on a selected interface.
Policy Name Enter the name of the policy to be applied.
PBR configuration example in the web interface
Network requirements
As shown in Figure 304, configure PBR based on policy aaa to send TCP packets received from
GigabitEthernet 0/1 through GigabitEthernet 0/2 (assume GigabitEthernet 0/2 has only one next hop
connected). Non-TCP packets are forwarded based on the routing table.
