Figure 309 Applying policy aaa to GigabitEthernet 0/1
Configuring PBR at the CLI
Defining a policy
To define a policy:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create a policy or policy
node and enter PBR policy
node view.
policy-based-route policy-name
[ deny | permit ] node
node-number
N/A
3. Define a packet length match
criterion.
if-match packet-length min-len
max-len
Optional.
4. Define an ACL match
criterion.
if-match acl acl-number Optional.
5. Set VPN instances.
apply access-vpn vpn-instance
vpn-instance-name&<1-6>
Optional.
6. Set an IP precedence.
apply ip-precedence value Optional.
7. Set outgoing interfaces.
apply output-interface
interface-type interface-number
[ track track-entry-number ]
[ interface-type interface-number
[ track track-entry-number ] ]
Optional.
Two interfaces at most can be
specified to send matching IP
packets. These two interfaces are
simultaneously active to achieve
load sharing.
For a non-P2P outgoing interface
(broadcast and NBMA interfaces)
such as Ethernet interface, multiple
next hops are possible, and thus
packets may not be forwarded
successfully.
