Figure 335 PIM neighbor information
Table 82 Field description
Field Descri
p
tion
Interface Name of the interface connecting to a PIM neighbor
Neighbor address IP address of a PIM neighbor
Uptime
Length of time for which the PIM neighbor has been up, where a
"01:02:11:32:18" value means that the neighbor has been up for 1
week, 2 days, 11 hours, 32 minutes, and 18 seconds.
Remaining lifetime
Remaining lifetime of the PIM neighbor, where a "00:02:45" value
means that the neighbor will time out in 2 minutes and 45 seconds and
"never" means that the PIM neighbor never times out.
PIM configuration example in the Web interface
Network requirements
As shown in Figure 336, receivers receive VOD information through multicast. The receiver groups of
different organizations form stub networks, and one or more receiver hosts exist in each stub network. The
entire PIM domain operates in the dense mode.
Host A and Host C are multicast receivers in two stub networks N1 and N2.
IGMPv2 runs between Firewall A and N1 and between Firewall B and N2.
