R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

610
Ste
p
Command Remarks
3. Configure the hello interval. pim timer hello interval
Optional.
30 seconds by default.
4. Configure the maximum delay
between hello messages.
pim triggered-hello-delay interval
Optional.
5 seconds by default.
5. Configure the join/prune interval.
pim timer join-prune interval
Optional.
60 seconds by default.
6. Configure the join/prune timeout
time.
pim holdtime join-prune interval
Optional.
210 seconds by default.
7. Configure assert timeout time.
pim holdtime assert interval
Optional.
180 seconds by default.
NOTE:
If no special networking requirements are raised, use the default settings.
Configuring join/prune message sizes
A larger join/prune message size will result in loss of a larger amount of information if a message is lost;
with a reduced join/message size, the loss of a single message brings relatively minor impact.
By controlling the maximum number of (S, G) entries in a join/prune message, you can effectively reduce
the number of (S, G) entries sent per unit of time.
To configure join/prune message sizes:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter public network PIM view. pim N/A
3. Configure the maximum size of a
join/prune message.
jp-pkt-size packet-size
Optional.
8100 bytes by default.
4. Configure the maximum number
of (S, G) entries in a join/prune
message.
jp-queue-size queue-size
Optional.
4096 by default.
Displaying and maintaining PIM
Task Command Remarks
Display BSR information in the PIM-SM
domain and locally configured C-RP
information in effect.
display pim bsr-info [ | { begin |
exclude | include } regular-expression ]
Available in any view
Display information about the unicast
routes used by PIM.
display pim claimed-route
[ source-address ] [ | { begin | exclude
| include } regular-expression ]
Available in any view
